Discovering and Downloading USGS Topographic Maps

On a nice summer day, you may be thinking about going for a hike or exploring areas for your research. Whether you are looking for current or historical topographic maps, there are a number of options to discover and download this maps for free. Included below are examples of how to locate printer friendly, historic, and Connecticut focused USGS Topographic Quadrangle maps.

Printer-Friendly USGS Topographic Maps

Recently National Geographic released a U.S. Geological Survey (USGS) topographic map PDF Quad interface which allows users to search for a location and then obtain printer friendly topographic maps for that area in PDF format. Included below is an overview of the process for searching and downloading your own topographic map which will print on an 8.5″ by 11″ paper as a multi-page map.

  1. Go to http://www.natgeomaps.com/trail-maps/pdf-quads and scroll down to the interactive map.
  2. In the search bar at the top right corner of the interactive map, search for a town, quadrangle, or place. search_national_geo_quad_PDF
  3. The map will zoom to your area of interest. If you do not see any red pins on the map, zoom out the map by clicking the minus (-) sign on the left side of the map. pins_maps_national_geographic_quad_PDF
  4. Click the red pin closest to your location of interest, this pin represents the center of the topographic quadrangle which covers the area. The pin will display a preview quadrangle map. Click on the quadrangle map image. map_preview_national_geographic_quad_PDF
  5. This will download a PDF map of the quadrangle map which includes a total of 5 pages, the first being an overview quadrangle map, the next 4 maps which include a section of each quadrangle. These maps are designed to be printed on 8.5″ by 11″ paper and include scale, latitude, longitude, along with all the other details included on a USGS topographic map. If you want to know more about the different symbols on the map, check out the USGS Topographic Map Symbols legend.

Historical Topographic Maps from USGS

The USGS also offers a national index of digitized historical topographic maps called topoView which allows you to search by location for historical topographic maps and to download the maps in JPEG, KMZ, GeoPDF, and GeoTIFF format. While these maps may not be as printer-friendly as the PDF Quads from National Geographic, the topoView interface provides nationwide access to historical topographic maps at a range of scales. Included below is a quick overview of how to use the topoView interface:

  1. Go to http://ngmdb.usgs.gov/maps/topoview/ and click on Get Maps.topoView_interface
  2. From the topoView browser, search for a location and hit enter. This will zoom the map to area of interest. From the map scales menu (along the right side of the map screen) select the map scale you are interested in viewing or select Show All to see all the scales available. topoView_mapscales
  3. Click on the orange map pin to bring up the map preview and download menu which will appear in the bottom left corner of the map. This will provide the option to download the map in JPEG, KMZ (Google Earth friendly format), GeoPDF, and GeoTIFF formats. If there is more than one map available, just to the right of the preview map will be a link with the number of maps available. In the sample below there are 13 historical maps to choose from for Hartford North, Connecticut.topoView_map_preview

Connecticut Historical Topographic Maps from MAGIC

If you are interested in more topographic maps for Connecticut, MAGIC offers a number of digitized topographic quadrangle maps which can be accessed via MAGIC’s website with a majority of this historic topographic maps available via the topoView application. Included below is a quick outline of how to locate and download topographic maps for areas in Connecticut from MAGIC’s website:

  1. Got to http://magic.lib.uconn.edu/topographic_maps.html and from the interactive Connecticut USGS Topographic Maps Mash-up interface, search for town (ex. Hartford, Connecticut).
  2. The map will zoom to the area of interest which will show a pin and an outline of the topographic quadrangle(s) nearby. Multiple scales of topographic maps may be available for your area and you can select which scale you want from the Toggle menu along the top right corner of the interactive map interface. More detailed maps will be at 1:24k scale while more general maps will be available at higher scales up to 1:125k.magic_topographic_maps_interface
  3. Click the topographic quadrangle outline which covers your area and a pop-up menu will appear. Select the map of interest and click the View and Download link.magic_topographic_maps_interface_popup
  4. This will take you to MAGIC’s Flickr page where you can download the map as a JPEG (down area in right corner of map view window) or as a full-quality TIFF image (link is located below image). magic_topographic_maps_flickr

Three separate interfaces, each providing access to USGS topographic maps and providing access to current and/or historical quadrangle maps. Enjoy exploring each interface!









Change in median household income in U.S. counties (adjusted for inflation), 1979-2014

This visualization converts county-level median household income from the 1980 Census to inflation-adjusted 2014 dollars, and compares these figures with the latest household income data from the 2010-2014 American Community Survey.

Diversity trends in undergraduate enrollments and faculty at research universities and colleges: 2001 to 2014

The following post and data visualization is by guest blogger Lisa Bernardo, highlighting her project for Prof. Harmon’s Economics Independent Study class.

This project aimed to analyze diversity of student enrollment versus faculty members at research universities in the United States.  Through our research and analysis, we wanted to determine whether the make up of the student population in terms of race and ethnicity was well represented within that of faculty members.  This was done by calculating race and ethnicity shares of undergraduate students and faculty members from the years 2001 through 2014 using data downloaded from the IPEDS Data Center.

From our analysis, it was concluded that the shares of black and Hispanic faculty members remained significantly below these shares for students consistently over the time period of 2001 to 2014.

We also found that shares of black and Hispanic students as well as faculty members did show significant increases from 2002 to 2014, though the faculty increase lagged the student increase.  The black and Hispanic enrollment share for undergraduate students increased from 4.04 percentage points from 14.87% in 2002 to 18.91% in 2014.  Whereas, this same share for faculty members only increased 3.16 percentage points from 12.65% in 2002 to 15.81% in 2014.

Estimated population change for selected age groups in U.S. counties, 2010-2015

This visualization draws on another dataset made available through the U.S. Census Bureau’s American FactFinder data engine, Annual Estimates of the Resident Population for Selected Age Groups by Sex for the United States, States, Counties, and Puerto Rico Commonwealth and Municipos: April 1, 2010 to July 1, 2015.T The Census Bureau’s Population Division releases yearly data  population estimates by age, race, and ethnicity which update the most recent decennial census counts with the latest birth, death, and international and domestic migration data. The estimates’ methodology incorporates a variety of data sources including IRS, Medicare, and American Community Survey datasets, as well as National Center for Health Statistics birth and death data.

Last month the Census Bureau’s Population Estimate Program released the latest estimates for states, counties, and county subdivisions, including total estimated population for Connecticut towns as of July , 2015.

Since the 2010 Census, it is estimated that 61 towns gained population, while 108 lost population; Fairfield County gained about 3.4%, while towns in Litchfield County together lost an estimated 3.3% of their population since 2010.



State lottery system revenue and expenditures, 2014

This dashboard highlights another table available through the U.S. Census Bureau’s American FactFinder data portal:  Income and Apportionment of State-Administered Lottery Funds: 2014 from the 2014 State Government Finances data program.

The data – which includes total revenues of lottery systems, expenditures in lottery system administration and prizes, and total lottery revenue made available to fund state government – show a wide range of both public participation and approaches to state lottery administration among the 43 state lottery systems.

Compared with figures from the 2014 American Community Survey, Massachusetts had the highest lottery revenues from its adult population on a per-capita basis – about $900 of revenue for each adult 18 and over. Massachusetts also had the highest rate of payout to winners – returning  72% of gross lottery revenues in the form of prizes.  25.6% of Massachusetts state lottery revenues were made available to the state, compared with the national average of 34.6% – yet the state still ranked 4th in total lottery proceeds made available to finance other state functions – yielding more than $1.2 billion to the state in 2014.

Arkansas had the lowest percentage of lottery revenues returned to state government – 20.4% – and was the 12th most costly state system to run in terms of lottery administrative costs as a percentage of gross lottery revenue. West Virginia lottery system allocated the smallest percentage of gross lottery revenue on prizes – 17.1% – and returned the highest percentage of lottery  revenue back to the state – 77.8% –  to be made available for other government functions.



Mapping Connecticut School District Data in Tableau

This is the third in a series of posts on using Tableau Desktop or Tableau Desktop Public Edition to map Connecticut data using custom polygons, to accommodate geographic entities not recognized innately in the Tableau mapping functionality. See these other posts for more information on creating filled maps for Connecticut towns and Census Tracts in Tableau:

Tableau and Tableau Public offer robust mapping capabilities, including the ability to recognize geographic entities in your data and instantly create choropleth (filled) maps with shapes for counties, states, and countries. For users that want to create filled maps for geographic entities not recognized innately by the software, Tableau supports the creation of polygon-shaded maps, allowing users to map data onto polygon shapes which correspond to sales regions, marketing areas, etc. The Connecticut State Data Center has created a number of custom polygon map files corresponding to Connecticut geographies not innately supported in Tableau, including Connecticut school districts:

CT_School_District_Polygons_for_Tableau

The directions below show you how to connect to this file to create a custom polygon map for school districts, and then join the Polygon data with some sample demographic data from the American Community Survey to create a filled/choropleth map. This is followed by additional tips to joining the polygon shapes with additional data sources, such as data from Connecticut Open Data, CTDataCollaborative, and Connecticut Department of Education.

Step 1: Setting up the School District polygon map:

  1. Save a copy of the CT_School_District_Polygons_for_Tableau Excel workbook (linked above) to your computer. Open Tableau Public or Desktop, and from the Data menu navigate to the Excel workbook, and drag the Polygons sheet into the data space. Click Go to Worksheet or open a new New Sheet on the task bar.connecting
  2. Under Measures in the Data pane, drag Longitude to the Columns shelf. Note that the Aggregation for this pill should be average; i.e. the pill should say AVG(Longitude). Aggregations can be changed if necessary (e.g. from Sum to Average) from the carrot menu for the measure in the rows or columns shelf.
  3. Drag Latitude to the Rows shelf. The aggregation should also be average (AVG) in the pill.
  4. In the Marks card, change the view type menu from Automatic to Polygon
  5. If Pointorder was placed in the Measures pane, it must be converted to a Dimension – simply drag it from Measures to Dimensions. Then, drag Pointorder to Path on the Marks card.
  6. Drag Polygon Number onto Detail on the Marks card.
  7. Drag District Name from Dimensions onto Color on the Marks card. (If a dialog window appears, confirm that you want to Add all members).
  8. To see the boundaries of districts more clearly, it is helpful to display borders around the polygons. To do this, click Color on the Marks card, and from the Border carrot menu, select a color. You should now see a map like this:map
  9. At this point, it’s important to note that mapping Connecticut school district data is a little tricky, because the varying administrative structures among districts creates overlapping geographies that makes it impossible to show all districts on a single map. There are three basic administration models for school districts in Connecticut, and geographically speaking, they aren’t mutually exclusive – as many towns send children to more than one district. Here are the three types (the names of the district types are from the Census Bureau (which publishes the shape files from which the polygons are derived); and may not correspond to local or state terminology):

Continue reading

Mapping Connecticut Census Tract data in Tableau

This is the second in a series of posts on using Tableau Desktop or Tableau Desktop Public Edition to map Connecticut data using custom polygons, to accommodate geographic entities not recognized innately in the Tableau mapping functionality. See these other posts for more information on creating filled maps for Connecticut towns and school districts in Tableau:

The U.S. Census Bureau aggregates and publishes Decennial Census and American Community Survey data at geographic levels large and small, including Census Tracts – small statistical subdivisions of roughly 1200-8000 people. Connecticut has 833 Census tracts; many small towns comprise a single Census Tract, while Hartford has more than 30. There are more than 7,500 data tables available through American FactiFinder for Connecticut Census tracts on demographic and economic measures including income and poverty, educational attainment, health insurance coverage, housing characteristics, and more. The steps below will let you create a choropleth map in Tableau for any Census Tract-level data downloaded from American FactFinder, enhancing the functionality of Tableau to analyze and visualize ACS and Decennial Census data.

Tableau support documentation includes instructions on converting ArcGIS shape files into spreadsheet files that Tableau can use to construct custom polygon maps. The Connecticut State Data Center has converted a number of U.S. Census Bureau TIGER/Line shape files into polygon data files for use in Tableau, including polygon  files for Connecticut towns, school districts, Census tracts, and legislative district boundaries. If you would like to visualize Connecticut Census Tract-level data on a map (as in this dashboard) in Tableau, this Excel workbook:

CT_Census_Tract_Polygons_for_Tableau.xlsx

of Connecticut Census Tract polygons contains a Polygon spreadsheet that will render a map of all Census tracts within Connecticut, and an additional sheet of housing value data from the American Community Survey that you can link with the polygon map, following the steps below, to create a choropleth map like the one below (click image to see full size). Additional information will help you download more tract-level data from American FactFinder, and join and map it with the Polygon data.

8

Each of the 29,202 rows of the Excel Polygon sheet describes a single point on the outline of a single tract’s boundaries, with a field for longitude and latitude of the point. Another field for each row is Point Order, which tells Tableau in which order to ‘connect the dots’ to form each tract on the map. For example, Mansfield’s shape has 208 points in the data set. Tableau draws each polygon by starting with the latitude and longitude of point 1, then continues drawing the shape until it gets to point 208, completing the outline of the town. The software does this for all 29,000+ points on the map instantly, whether in Tableau Desktop or Public, and map tools seem to work as quickly with a polygon map published to Tableau Public as any boundaries innately recognized in Tableau.

Step 1: Setting up the polygon map:

Continue reading

142 counties – with 92 million residents – experienced a significant increase in income inequality from 2008-2013

According to the U.S. Census Bureau’s American Community Survey estimates, income inequality increased significantly in 142 U.S. counties between the 2008-10 and 2011-13 survey periods. While this is relatively small compared to the number of counties where there was no significant change (1,688), almost 92 million people – nearly 30% of the U.S. population at the time – resided in these counties in 2013. Eleven counties – with a combined population of 565,00 – had significantly reduced income inequality over the 2011-2013 ACS survey period, compared with 2008-2010. Click any county in the map below to see a link to the original ACS data in the American FactFinder data engine.

This visualization uses table B19083 Gini Index of Income Inequality  from the 2010 and 2013 ACS 3-Year Estimates and compares the values for each county, and their margins of error, between the survey periods. Counties with very close Gini Index values from the two surveys (where the confidence intervals overlap) are considered not to have experienced a statistically significant change in income inequality. Counties which have an upper bound of the 2008-10 confidence interval which is smaller than the lower bound of the 2011-13 confidence interval are considered to have had a statistically significant increase in income inequality income between the two survey periods. Conversely, those counties which have a lower bound of the 2008-10 confidence interval which is greater than the upper bound of the 2011-13 confidence interval are considered to have experienced a statistically significant decline in median household income.

The 3-Year Estimates data series (now discontinued) reported data for counties with populations of 20,000 or more, so counties with smaller populations are excluded from the analysis. The counties in the map below had an aggregate total population of 301 million in 2013, compared with the total U.S. population 314 million at the time. The release of the ACS 2011-2015 5-Year data set in December 2016 will allow similar analysis for all U.S. counties, including those with populations under 20,000. Data from this survey will be able to be compared to results from the 2006-2010 5-Year data.

The Gini Index represents the concentration of income in a given state or country, in a range from 0 to 1. A higher Gini index indicates greater inequality – where income is concentrated among a relatively few individuals or households; a lower Gini score represents more even income distribution. The Gini index is a commonly used economic measure, reported by organizations such as the World Bank and CIA, in its World Factbook.

Change in median household income within U.S. counties between 2004-09 and 2010-14 American Community Surveys

This visualization compares county-level median household income from the 2004-2009 and 2010-2014 American Community Survey 5-Year Estimates and compares the confidence intervals of the surveys to determine whether there was a significant increase or decline in median household income between the surveys, or no statistically significant change. Estimates from the 2004-2009 survey were converted to 2014 inflation-adjusted dollars using the Bureau of Labor Statistics’ ‘Consumer Price Index – All Urban Consumers‘ benchmark. These adjusted figures were compared with the median household estimate from the 2010-14 ACS (which were originally published in 2014 inflation-adjusted dollars).

Counties with inflation-adjusted median household income estimates with overlapping margins of error between the two surveys (when both survey estimates are expressed in 2014 inflation-adjusted dollars) are considered not to have experienced a statistically significant change in median household income between the survey periods. Counties which have an upper bound of the 2004-2009 confidence interval which is smaller than the lower bound of the 2010-2014 confidence interval, are considered to have had a statistically significant increase in median household income between the two survey periods. Conversely, those counties which have a lower bound of the 2009-2014 confidence interval which is greater than the upper bound of the 2010-2014 confidence interval are considered to have experienced a statistically significant decline in median household income.

The American Community Survey data showed statistically significant increase in median household income in 88 counties between these survey periods; 2,378 showed no significant change, and 677 a statistically significant decrease in median household income. Notably, the majority of the U.S. population lives in the counties that showed a significant decrease in household income: according to the 2014 ACS population figures, about 202 million people – 64% of the U.S. population – resided in these 677 counties.

Note that this visualization’s inflation adjustment uses national level Consumer Price Index, which may not reflect inflation differences that exist across geographies or regional differences in housing, transportation, or other sectors. The American Community Survey confidence intervals used here are the originally published data, which was reported at a 90% confidence interval.
